DOLPHIN LX 0430 C

Series: DOLPHIN series Manufacturer: Busch Technology: Liquid ring vacuum pumps Industries: Waste management and recycling, Automotive and transport, Battery manufacturing, Mining, Chemicals, Carbon capture (CCUS), Energy, Fish farming and aquaculture, Research, laboratory and analytics, Woodworking, Refrigeration and air conditioning, Power generation, Plastics and recycling, Food and beverage, Medical and healthcare, Metallurgy and heat treatment, Dairy, Oil and gas, Pharmaceuticals and biotechnology, Confectionery and bakery, Industrial gases, Environmental and wastewater, Packaging, Hydrogen and fuel cells Applications: Filling and sealing, Extraction of chips, dust and liquids, Centrifugal pump priming, Biogas, landfill and digester gas, Carbon capture processes, Distillation and solvent recovery, Degassing, Evacuation and charging (refrigeration, air conditioning, brakes), Evacuation of chambers and vessels, Extruder degassing and extrusion, Gas and vapour recovery, Gas liquefaction, storage and industrial gases, Freeze drying, Glycol regeneration (MEG, TEG), Vacuum cooking and extraction, Condenser air extraction, Seawater deaeration, Anaesthetic gas scavenging, Pneumatic conveying, Recycling (plastics and batteries), Steel degassing, Sterilisation, Parts cleaning and vacuum cleaning, Thermoforming, Transformers, capacitors and insulating oil, Tumbling, cutting and filling (meat), Vacuum filtration, Vacuum impregnation, Vacuum cooling, Vacuum drying, Vacuum packaging, Evaporation and concentration

The Busch DOLPHIN LX 0430 C is a liquid ring vacuum pump with a nominal pumping speed of 375 m³/h (50 Hz) or 455 m³/h (60 Hz) and an ultimate pressure of 33 mbar. Ehrler & Beck advises on selection and service.

Request a quote for this product Read more

  • Pumping speed 375 m³/h 50 Hz 455 m³/h 60 Hz
  • Ultimate pressure 33 mbar
  • Rated motor power 11 kW 50 Hz 15 kW 60 Hz

Busch DOLPHIN LX 0430 C – liquid ring vacuum pump

The Busch DOLPHIN LX 0430 C is a liquid ring vacuum pump. The nominal pumping speed is 375 m³/h (50 Hz) or 455 m³/h (60 Hz), the ultimate pressure 33 mbar. Nominal motor rating 11 kW (50 Hz) or 15 kW (60 Hz).

Features

  • Robust: proven technology, very high particle and vapour tolerance, corrosion-free stainless steel impeller
  • Compact: directly flanged motor, no base frame needed
  • Flexible: housing made of grey cast iron (EN-GJL-200) or stainless steel 316, ATEX version (cat. 2 (i) IIB T4), operating liquids other than water possible

Typical applications

Busch lists: Automotive and transport (vacuum cleaning / parts to be cleaned); Batteries (recycling); Biogas handling (circulation); Carbon capture (membrane separation, amine scrubbing, pressure swing adsorption and others); Chemistry (packaging, filtration, degassing, distillation, solvent recovery and others); Confectionery (other coatings, pneumatic conveying, moulding and forming and others); Dairy products (cheese production – vacuum chambers for cheese, cheese production – pneumatic conveying, cheese production – cheese towers and others); Fish farming (pneumatic suction conveying of ice for cooling, extraction of slaughterhouse waste, holding vacuum for filleting and others); Food processing (pneumatic conveying of wet food waste, meat tumblers and marinators, powder processing and others); Medical (ETO and steam sterilisation, anaesthetic gas scavenging); Mining (priming of the water pump); Packaging (liquid packaging); Pharmaceuticals and biotechnology (freeze drying, lyophilisation, distillation, solvent recovery, filtration, degassing and others); Plastics processing (pyrolysis, extruder and melt degassing, profile calibration); Power generation (water box priming); R&D (freeze drying, lyophilisation); Waste water treatment (aeration process); Woodworking (impregnation, drying).

Accessories and versions

  • Open or closed liquid circuit
  • Liquid separator
  • Cavitation protection
  • Heat exchanger
  • Gas ejector
  • Wide choice of motors
  • Non-return valves
  • Vacuum relief valves
  • Various operating liquids possible
  • ATEX – for safe operation in potentially explosive atmospheres

Advice and service

Ehrler & Beck advises on selection, accessories and service.
